Description
HGLRC Racewhoop30 3" FPV Racing Drone Black analog version Caddx Ratel 2 FPV Camera Zeus 800mW VTX
Features:
*Made of composite material, super explosion resistant;
*Fluorescent effect, 5 colors optional, ultra-high color value;
*With 2105.5 motor, super powerful and violent;
*3 Inches Racewhoop frame, compact and fly anywhere you want;
*Racewhoop Structure design, strong and No damage to the the frame or the components.
*Power plug:XT60
Product Name:HGLRC Racewhoop30 FPV Racing Drone 4S/6S Analog version
Weight:293.3g
HGLRC Racewhoop30 Frame
Culvert ring: black/Mixed colour/Pink/Green/Purple/Yellow
Model:3 inches Racewhoop Frame
Wheelbase:147mm
Size:200*200mm
Zeus F722 mini flight controller
Gyro:BMI270
Input voltage:3-6S Lipo
BEC output:5V/2A, 9V1A
Firmware:HGLRCF722
Zeus 28A BL_S ESC
Input voltage:3-6S
Continuous current:28A
Peak current:35A (10 seconds)
Firmware:BLS-F-H-40
Zeus 800mW VTX
Output Power:PIT/25/100/200/400/800mW
Input Voltage:DC6-26V
Antenna:MMCX
Caddx Ratel 2 Camera
Image Sensor:1/1.8 " 1200TVL CMOS
Input Power:DC 5-40V
Dimensions:19mm*19mm*20mm
AEOLUS 2105.5 3600KV motor
Motor:KV3600
Input voltage:3-4S
Recommended props:3 inches
Mounting hole:4*M2-∅12
AEOLUS 2006 2800KV motor
Motor:KV2800
Input voltage:4-6S
Recommended props:3 inches
Mounting hole:4*M2-∅12
GEMFAN D76mm 3 inch 5-blades propellers
Quantity:4 CW & 4 CCW
Package includes:
1x Zeus F722 mini flight controller
1x Zeus 28A BL_S ESC
4x AEOLUS 2105.5 3600KV motor/AEOLUS 2006 2800KV motor
1x Racewhoop30 Frame
1x Zeus 800mW VTX
1x Caddx Ratel 2 Cam
8x GEMFAN D76mm 5-blades propellers
1x mini Hammer Antenna (RHCP)
1x Receiver (optional)
Recommended battery:
4S:850mah-1300mAh
6S:850mah-1300mAh
