Description
HGLRC Sector30CR 3inch Cinewhoop Freestyle FPV Drone Sector150 Upgraded Version with Zeus nano 350mW VTX
Features:
Compared to the previous Sector150 version, the new one is upgraded with Zeus F728 stack and equipped with Aeolus 2004 motor,which makes the drone Sector30CR more powerful and fly with a longer distance.
Power plug:XT30
Product model:HGLRC Sector30CR Cinewhoop Freestyle 3 inch FPV Drone 4S
Net Weight:190g
Sector30CR Cinewhoop Freestyle frame
Wheelbase:150mm
Model:3 Inches frame
Zeus F722 mini flight controller
Input voltage:3-6S Lipo
MPU:BMI270
Zeus 28A BL_S ESC
Input voltage:3-6S
Continuous current:28A
Peak current:35A (10 seconds)
Zeus 350mW VTX
Output power:PIT/25/100/200/350mW
Input voltage:DC 5V
Antenna interface:IPEX
Caddx Ratel 2 FPV Camera
Image Sensor:1/1.8 " 1200TVL CMOS
Input Power:DC 5-40V
Dimensions:19mm*19mm*20mm
AEOLUS 2004 3000KV brushless motor
Motor:KV3000
Input voltage:4S
AEOLUS 2004 1800KV brushless motor
Motor:KV1800
Input voltage:6S
GEMFAN D76mm 3-inch 5-blades propeller
Quantity:4 CW& 4 CCW
Shipping list:
1x Sector30CR Frame
1x Zeus F722 mini Flight Controller
1x Zeus 28A BL_S ESC
1x Zeus 350mW VTX
1x Caddx Ratel 2 FPV Camera
4x AEOLUS 2004 3000KV brushless motor/AEOLUS 2004 1800KV brushless motor
8x GEMFAN D76mm 5-blade propeller
1x IPEX Hammer Antenna (RHCP)
1x Black TPU GP Camera fixing base
1x Black TPU Naked Camera fixing base
1x Receiver (optional)
Recommended battery:
4S:550mah-1000mAh 6S:550mah-1000mAh
See Manual Here
